Nauti Lift
1 / 5
Automatic guided vehicle (AGV) is a portable robot that follows along lasers lidar for navigation. They are most often used in industrial applications to transport heavy materials around a large industrial building, such as a factory or warehouse.
| No. | Specification | Detail | No. | Specification | Detail |
|---|---|---|---|---|---|
| 1 | Type | Electric | 17 | Min. Ground Distance | 20 mm |
| 2 | Navigation | Laser lidar | 18 | Stacking Channel Width | 1900 mm |
| 3 | Load Capacity | 1000 kg | 20 | Turning Radius | 980 mm |
| 5 | Axis Distance | 875 mm | 21 | Speed (empty/full) | 0.7/0.6 m/s |
| 6 | Tire Material | Polyurethane | 22 | Lift Speed (empty/full) | 150/90 mm/s |
| 8 | Steering Model | Electric Differential | 24 | Gradeability | 4/1 % |
| 10 | Overall Height | 450 mm | 26 | Driving Motor | 0.6 kw |
| 11 | Lifting Height | 70 mm | 28 | Lithium Battery | 48V/24Ah |
| 13 | Overall Length | 1460 mm | 30 | Total Weight | 110 kg |
| 14 | Overall Width | 735 mm | 31 | Charging | Auto |
Welcome more clients to be our agent to develop and service local market. We will provide more supports to our agent. We are glad to be OEM/ODM of our client to extend the business.
