Streamlined appearance with professional aesthetic design.
HELI specialized transmission box and drive axle with over 20 years of market verification.
Load sensing and dual pump confluence hydraulic technology for high efficiency and low energy consumption.
Advanced electric control technology co-developed with engine manufacturers for optimized performance.
Standard powered braking system offers quick-respond and effective braking; high capacity bag type accumulator.
Superior sealing and sound insulation technology to reduce operating noise.
Wide view lifting system and wide-angle rear view mirror for enhanced operator visibility.
LCD meter with CAN bus for real-time engine state monitoring.
New type steering wheel with dual thread adjusting mechanism.
Half shaft sealing technology on drive axle end improves sealing reliability.
Integrated modularized electric box with up to IP56 protection degree.
Clearance buffering structure on lifting cylinder bottom ensures stable lowering of goods.
Innovative "dual-lip elastic sealing gasket" to prevent oil tank cover leakage.
Extraposition structure of transmission box oil filter and hydraulic return oil filter makes maintenance and repair easy. Air cleaner assembled on truck meeting China emission standard stage III has good universality. Service access is added between balance weight and overhead guard for convenience.
| Parameter | Model | CPCD100 |
| Power type | Diesel | |
| Rated capacity | 10000 kg | |
| Load center | 600 mm | |
| Lift height | 3000 mm | |
| Wheel-base | 2800 mm | |
| Performance | Travel speed (load/no load) | 23/26 km/h |
| Lift speed (load/no load) | 310/340 mm/s | |
| Max. gradeability | 20% | |
| Brake system | Hydraulic-Foot pedal | |
| Engine | Model | LR6B5-22 |
| Manufacturer | YTO | |
| Rated power | 88.2/2200 kw |
